Ремкомплект циліндра гальмівного CAT 1135048>113-5048

Бренд: CATERPILLAR
Артикул: 1135048

Замовляйте за телефоном
+38(097) 112-34-95

Caterpillar 416B 416C 426C 428C 436C 438C 438D 442D

Рекомендовані товари

Pos.	Part No	Qty	Parts name	Comments
1.	4E-8619 Y	[1]	RESERVOIR GP-BRAKE
2.	9R-9334	[1]	BRACKET AS
2A.	5G-8108	[1]	CLAMP
4.	1P-4278	[8]	CLAMP-HOSE
5.	8T-4136 M	[2]	BOLT (M10X1.5X25-MM)
6.	8T-4133 M	[4]	NUT (M10X1.5-THD)
7.	8T-4121	[4]	WASHER-HARD (11X21X2.5-MM THK)
8.	1A-5350	[2]	CLIP
9.	3J-1907	[4]	SEAL-O-RING
10.	5P-1442 E		HOSE (22.5-CM EACH)
11.	8T-4224	[12]	WASHER-HARD (8.8X16X2-MM THK)
12.	9R-9701 J	[1]	CYLINDER AS
	113-5049	[1]	TUBE AS
13.	6V-8641	[4]	CONNECTOR
14.	9R-2806	[2]	PIN
15.	9R-2807	[2]	CLIP (RETAINER)
16.	8T-4815	[2]	ROD END
17.	9R-9333	[1]	PLATE
18.	9R-8183	[1]	BRACKET AS
19.	8T-4138 M	[4]	BOLT (M6X1X20-MM)
20.	8T-4205	[4]	WASHER-HARD (7.2X14.5X2-MM THK)
21.	4J-5477	[6]	SEAL-O-RING
22.	9F-2167	[2]	SCREW-PURGE (3/8-24X1.164-IN)
23.	5C-7261 M	[6]	NUT (M8X1.25-THD)
24.	9R-8192	[1]	TUBE AS
25.	9R-8191	[1]	TUBE AS
26.	9R-8185	[2]	SPACER (22.5X37X51-MM THK)
27.	9R-8186	[2]	SPRING
28.	9R-8184	[1]	PIN AS
29.	9R-8189	[2]	PUSHROD
30.	1H-1200 C	[1]	PIN-SPRING
31.	104-5497 C	[1]	PLATE
32.	092-7761 I	[2]	HOSE AS
33.	9R-8187	[1]	PEDAL AS (RH)
33A.	091-4471	[1]	BUSHING
35.	9R-8188	[1]	PEDAL AS (LH)
35A.	091-4471	[1]	BUSHING
37.	5P-6442 E		HOSE (64-CM EACH)
38.	7X-2537 M	[4]	BOLT (M8X1.25X35-MM)
39.	8T-4189 M	[2]	BOLT (M8X1.25X20-MM)
40.	8Y-8044	[2]	CONNECTOR
			AVAILABLE REPAIR KIT(S):
	113-5048 J	[1]	KIT-BRAKE CYLINDER
			(INCLUDES DUST COVERS, VALVE ASSEMBLIES, INSERTS, SEALS, WASHERS & CIRCLIPS)
